Wheeled Skid Steer Loaders | 500–1500kg Capacity

Why wheeled is the default choice

If your work is predominantly on hard-packed, paved or concrete surfaces, wheeled is almost always the better economic decision:

Lower purchase price — typically 25% to 45% less than the equivalent tracked machine
Lower running cost — tyres last far longer than tracks and cost far less to replace
Higher travel speed — faster repositioning between work areas reduces wasted hours
Simpler maintenance — no track tension, no undercarriage wear components

Capacity bands

Class	Rated capacity	Engine	Typical applications
Compact	500 – 700 kg	25 – 45 hp	Light material handling, landscaping, small yards
Mid frame	700 – 1,100 kg	45 – 75 hp	General construction, agriculture, most common choice
Large frame	1,100 – 1,500 kg	75 – 100 hp	Heavy material handling, quarry support, large-scale work

The mid frame band is where the majority of global sales sit. It offers the best balance of lifting power, manoeuvrability and cost.

Model specifications

Current production range, wheeled line. All figures are taken from the factory specification sheet — ask for the full datasheet (31 measurement items) with your quotation.

Specification	TA35	TA45	TA60	TA65	TA75	TA100	TA120
Rated operating load (kg)	500	700	850	950	1050	1100	1200
Rated power (kW)	37	37	45	55	55	74	103
Bucket capacity (m³)	0.3	0.4	0.4	0.5	0.5	0.55	0.55
Operating weight, with bucket (kg)	2300	2700	2800	3400	3500	3550	3600
Dead weight (kg)	2600	3000	3200	3400	3800	4000	4000
Overall width (mm)	1350	1720	1880	1880	1880	1880	1880
Max operating height (mm)	3300	3980	4000	4070	4070	4070	4070
Dumping height (mm)	2000	2380	2400	2450	2450	2450	2450
Max travel speed (km/h)	10	12	12	12	12	12 / 18	12 / 18
Ground clearance (mm)	140	185	205	205	205	205	205
Hydraulic flow (L/min)	60	62.5	75	75	75	75	75
Fuel tank capacity (L)	60	70	80	75	75	90	90
Tyre / track model	8.5-16.5	10-16.5	12-16.5	12-16.5	12-16.5	12-16.5	12-16.5

The entry model TA25 (380 kg rated load, 920 mm wide) is listed under mini loaders. Low-profile TA35D / TA50D and remote-controlled TA35Y variants of this platform are listed on the range overview.

Typical applications

Site clearance, backfilling and material handling
Loading trucks, hoppers and mixers
Agricultural feed handling, barn cleaning and grading
Warehouse and yard material movement with pallet forks
Road sweeping and municipal maintenance work
Landscaping, grading and trenching

Specify the right machine

Before requesting a quotation, work out:

Your heaviest typical payload plus attachment weight (this sets your minimum ROC)
The dump height you need to clear
Whether you will run attachments requiring high-flow hydraulics
Which engine brand has the strongest local parts support
Whether an enclosed A/C cab is needed for your climate

From the factory floor

Real machines photographed at our works. More photos and videos are available on request.

Wheeled skid steer loader with bucket raised

Wheeled skid steer loader, three-quarter view

Not sure which model fits?

Tell us your working conditions, payload requirements and destination port. Our export team will recommend the right configuration and send a full quotation within 24 hours.

Request a Quote →
